Home » Products » Filling Machine » Small Pet Plastic Glass Bottle Automatic 3-in-1 Monoblock Fruit Juice Beverage Soft Drink Liquid Filling Packing Machine

Small Pet Plastic Glass Bottle Automatic 3-in-1 Monoblock Fruit Juice Beverage Soft Drink Liquid Filling Packing Machine

2000BPH High Efficiency Automatic Top Pure Water Liquid Filling Machine Production Line Solutions

Small Pet Plastic Glass Bottle Automatic 3-in-1 Monoblock Fruit Juice Beverage Soft Drink Liquid Filling Packing Machine


Availability:

Quantity:

Inquire Add to Basket

Model:
CGF14-12-5
Brand:
ZEGO

This juice beverage filling machine is suitable for the production of a variety of juice beverages, such as orange juice, mango juice, strawberry juice, blueberry juice, apple juice, and pear juice. By replacing a few parts, it can also be used to fill purified water and mineral water. This juice beverage filling machine utilizes a micro-negative pressure gravity filling principle, offering fast, stable, and accurate filling. It also features a comprehensive material return system that allows for independent air return during reflux, preventing contact with the material and reducing secondary contamination and oxidation.

Product Description

Introdution

The juice beverage filling machine line meets hot-filling requirements below 95℃.An RO water rinse system flushes the bottle mouth before capping to prevent mold.The juice beverage filling machine utilizes a magnetic torque-operated capping head for both gripping and capping.The capping torque is infinitely adjustable,providing a constant torque for capping.

The juice beverage filling machine utilizes a touchscreen human-machine interface and features automatic filling temperature monitoring,high temperature material alarm,low temperature shutdown and automatic reflow,no-capping,bottle-out waiting,and cap-out shutdown functions.

Basic

Model Number	CGF 14-12-5
Bottle Size	50ML to 2000ML
Install Power	5KW
Machine Overall Size	220015002650mm
Capacity	4000-5000BPH
Feed Cylinder Structures	Multi-Room Feeding
Filling Principle	Pressure
Material	SUS304;S316
Filling Tolerance	±2%
Rinsing Consumption	1T
Filling Valve Type	Mechanical Filling Valve-Gravity Filling

Machine Details

Introduction

Bottling Washing

1. The bottle channel is fed by an air delivery device directly connected to the bottle scale.
2. All 304/316 stainless steel cleaning heads feature a water-spraying design for water conservation and improved cleaning.
3. 304/316 stainless steel grippers with plastic pads minimize bottle impact during cleaning.
4. 304/316 stainless steel cleaning pumps enhance machine durability.
Bottling Filling

1. 304/316 stainless steel high-precision filling nozzle
2. Filling volume can be finely adjusted to ensure consistent liquid level after filling
3. All 304/316 stainless steel contact parts and liquid tank are finely polished, eliminating dead corners and making them easy to clean
4. 304/316 stainless steel filling pump
Bottling Capping

1. Placement and capping system, featuring an electromagnetic capping head with unloading function, minimizes bottle impact during capping.
2. All 304/316 stainless steel construction.
3. No bottle, no cap.
4. Automatically stops when there are no bottles.
5. Stable and reliable sealing performance, with a failure rate of ≤ 0.2%.

With Customer&Package

2000BPH water bottle complete line shipping to Colombia

2000BPH juice bottle complete line shipping to South Africa

微信图片_20250625171448

微信图片_20250703164228

Prouduction Line

Introduction

Water Treatment

We adopt different equipment to produce pure water, mineral water etc. The main equipment of RO Water Treatment Plant are silica sand filter, active carbon filter, sodium ion exchanger, hollow fiber, RO, UV sterilizer, precision filter, ozone generator, water tank etc.
Bottle Blowing Machine

Bottle blowing machine adopts our most advanced blowing technologies. This machine is a high intelligent, stable and reliable blowing machine,with simple structure,and low energy consumption.
Filling Machine

CGF water filling machine adopts the suspension design. It allows the machine to fill different type of the bottles. It is normally used as drinking water filling machine. However, it can also be used for fill PET bottle with fruit juice and tea drinks at high temperature by simply change the accessories.
Labeling Machine

Including PVC Shrinking Labeling Machine, OPP labeling machine, Self-adhesive / Sticker labeling machine, Etc.
Widely used for different material of container and label. The label cost is comparatively lower, it can meet therequirements of those users who have diverse kinds of the containers.
Package Machine

PE film heat shrink wrapping machine is suitable for wrapping of such products as pop top, mineral water, bottles, drinks etc. Working with PE film shrink tunnel to pack the goods perfectly , the whole production process adopts the Germany advanced technics, and the main parts are imported from international famous company.
