| Quantity: | |
1.Features a premium single-chip microcomputer control system, delivering consistent long-term performance and minimizing breakdown risks.
2.Boasts an integrally cast frame that boosts overall structural rigidity and anti-vibration capability, guaranteeing steady equipment operation.
3.Employs infrared lamp heating (boasting strong penetrability) paired with rotating bottle preforms and orbital uniform heating, achieving rapid, uniform, and dependable heating results.
4.Equipped with width/height adjustable baffles inside the heating tube to accommodate various bottle preforms; a built-in automatic exhaust function preserves heating stability.
5.Incorporates safety self-locking devices for every mechanical movement; the system will automatically shift to a safe mode in the event of a process malfunction.
6.Adopts cylinder-driven operations (eliminating the need for an oil pump), enabling pollution-free running and low operational noise.
| ZG500B | ||
| Container | Clamping Force(KN) | 100 |
| Clamping Stroke(MM) | 215 | |
| Stretching Stroke(MM) | 400 | |
| Cavity | 1-2 | |
| Capacity(BPH) | 1000-2200 | |
| Max.Bottle Volume(LTR) | 6 | |
| Max.Neck Diameter(MM) | 120 | |
| Max.Bottle Diameter(MM) | 185 | |
| Max.Height(MM) | 380 | |
| Electric Sydstem | Total Power(KW) | 8 |
| Heating Power(KW) | 5 | |
| Machine Specification | Blower size(MM) | 1900×650×1800*2 |
| Blower weight(MM) | 750*2 | |
| Heater size(MM) | 1700×670×1600 | |
| Heater weight(MM) | 350 |
